UPS
100Ah LIB Module
FlexLi-V Serials
VestWoods Lithium Iron (LiFePO4) UPS batteries are tailored for the unique power backup needs of data centers and internet data centers. With their high energy density and extended cycle life, these batteries deliver reliable and efficient backup power to safeguard critical servers, storage systems, and networking equipment in both DC and IDC environments. Equipped with advanced protection features, VestWoods batteries ensure the safety and uninterrupted performance of your valuable data center infrastructure. Choose VestWoods for dependable power solutions in data centers and internet data centers. Voltage Range: 265-512V Energy Range: 12.8kWh-1MWhTechnical Parameter
| Item | Description | |
|---|---|---|
| System | type | FlexLi-512V-100Ah |
| Cell Materials | LFP | |
| Rated Voltage | 512VDC | |
| Norminal Charge Voltage | 544VDC | |
| Max CHG/DHG Current | 1C@100A/3C@300A | |
| Cycle Life | 4000 cycle @80%DOD, 0.5C, 25°C | |
| Norminal Energy | 51.2kWh @ 0.5C(488-544VDC) | |
| Weight | Approx. 695KG | |
| Size | 800mm*800mm*2000mm | |
| Self-Discharge@25°C | <2%/month | |
| Communication | CAN, RS485, DI/DO, SNMP(Optional) | |
| Protection | OV/UV, OT/UT, OC, Short Circuit etc. | |
| Certification | EN 61000, IE62619, UN38.3 | |
| Environment | Storage Temperature | 0-45° |
| Operation Temperature | 0-45° | |
| Humidity | <95% | |
| Altitude | 0~4000 meters | |
| FlexLi-512V-100AH | Cell | Moudle | Cluster |
|---|---|---|---|
| Pack | 1S1P | 20S1P | 160S1P |
| Norminal Energy | 320Wh | 6.4kWh | 51.2kWh |
| Norminal Voltage | 3.2VDC | 6.4VDC | 512VDC |
| Voltage Range | 2.5VDC-3.6VDC | 56VDC-720VDC | 448VDC-544VDC |
| Size(W*D*H) | 130.2*40.2*220mm | 310*616*274.5mm | 800*800*2000mm |
| Weight | 2.35KG | Approx. 60KG | Approx. 695KG |
